Additional information
| Dimensions | 81.3 × 81.3 × 15.2 mm |
|---|---|
| Vendor | AccelTex Solutions |
| Country of Origin | China |
| Antenna Gain | 2 dBi |
| Beamwidth - Horizontal | 360° |
| Beamwidth - Vertical | 90°/90° |
| Cable Length | 457mm |
| Cable Type | RG174 |
| Connector Type | 3 SMA 1-GPS/2-LTE |
| Frequency Rating | GPS: 1575.42±3 MHz / LTE: 698-960/1710-2690 MHz |
| Antenna Type | Omni Antenna |
| Impedance | 50 Ohms |
| Indoor/Outdoor | Outdoor |
| Installation Type | Threaded Bolt with Nut |
| Radome Material | ABS |
| Number of Leads | 3 |
| Operating Temperature | -40 to 85 °C |
| Polarisation | GPS: RHCP, LTE: Linear |
| Wi-Fi Standard | 802.11ac (Wi-Fi 5), 802.11n (Wi-Fi 4) |
| Voltage Ratio | GPS: < 1.5 / LTE: ≤2 |
